79
To set all channels at the same time, go to {Rate} and press the [Select] button.
E) Audio Recording/Live setting
Sets the Recording/Live status for the audio input from an external device that is compatible with
the system
On the {Recording Setup} {Data 1~4} {Recording} {Audio} menu, go to the channel using
the
arrow (STW X) buttons and press the [Select]
button.
On the selection box, set the audio channel using the arrow (ST) and [Select] buttons.
(7) Event setup
A) Motion
Used to detect motion
Detection settings include Full, Partial, and OFF. The default setting is OFF.
The full video of a certain channel is displayed as shown below (blocks are used to separate the
areas where motion is detected).
The blue block indicates the areas where motion is detected.
Full
Used to detect motion in each zone
On the {Recording Setup} {Data 1~4} {Event} (Motion) menu, go to the channel using
the arrow (STW X) buttons and press the [Select] button.
Motion is not detected. Motion is detected only in the
selected zones
Motion is detected in all zones.
