PCI Configuration Space Register Description
4-11
Version 2.2
Copyright © 2001, 2002, 2003 by LSI Logic Corporation. All rights reserved.
Register: 0x20–0x23
Memory [1] High
Read/Write
The
register and the
register map the
RAM into Memory Space [1]. This register contains the upper 32 bits of
the Memory Space [1] base address. The LSI53C1030 requires
64 Kbytes of memory for Memory Space [1].
Memory [1] High
[31:0]
This field contains the Memory [1] High address.
Register: 0x24–0x27
Reserved
Reserved
[31:0]
This register is reserved.
Register: 0x28–0x2B
Reserved
Reserved
[31:0]
This register is reserved.
31
