User’s Manual of MGSW-28240F
6.27 ERPS Command
erps add
Description:
Create a new ethernet ring protection group.
<group-id> : protection group id.
<east_port> : protection group Port 0.
<west_port> : protection group Port 1, Port 1 can be 0 for sub-rings.
[major|sub] : ring type i.e major-ring or sub-ring.
[interconnected] : interconnection node or not.
[[virtual_channel] : Virtual channel present or not.
[<major-ring-id>] : major ring group Id for interconnected sub-ring.
Syntax:
Erps add <group-id> <east_port> <west_port> [major|sub] [interconnected] [virtual_channel] [<major-ring-id>]
Parameters:
<group-id> : protection group id 1 – 64.
<east_port> : Port 0 of a protection group.
<west_port> : Port 1 of a protection group.
major|sub : ring type.
interconnected : Set for interconnected node.
virtual_channel: Set for virtual channel.
<major-ring-id>: major ring of a sub-ring, when configuring as an interconnected node.
Example:
MGSW-28240F:/>erps add 1 1 2 major
erps mep
Description:
Associating Port 0/1 MEP to a protection group.
<east_sf_mep> : Mep_ID for finding out Continuity Check errors on Port 0.
<west_sf_mep> : Mep_ID for finding out Continuity Check errors on Port 1.
<east_raps_mep> : Mep_ID for transmitting R-APS frames on Port 0.
<west_raps_mep> : Mep_ID for transmitting R-APS frames on Port 1.
<group_id> : protection group id for which mep is associating.
