1.4 Product Specifications
Product
ICA-W8100
Wireless Cube Fisheye IP Camera
Camera
Image Device 1/4” progressive 1.3 mega-pixel scan CMOS sensor
Lens Fish-Eye Lens, 185.5/145/>=200° (H/V/D), F= 2.0, f=0.89 mm
Min. Illumination 0.5 lux @ F2
Effective Pixels 1280 x 720 pixels (16:9)
PIR Sensor
1 x Built-in sensor with adjustable 70 degrees direction
Effective Distance: 5 meters
Effective Coverage: 70 degrees
Video
Video Encoder H.264 / MPEG-4 / M-JPEG
Video Resolution
H.264: 1280 x 720 / 640 x 360 / 320 x 180
MPEG4: 1280 x 720 / 640 x 360 / 320 x 180
M-JPEG: 1280 x 720 / 640 x 360 / 320 x 180
Frame Rate Up to 30fps for all resolutions
Image Setting AE, AWB, Brightness, Saturation, Contrast, Mirror/Rotate, Color/BW
Streaming
Simultaneously multi-profile streaming
Streaming over UDP, TCP, or HTTP
M-JPEG streaming over HTTP (server push)
Controllable frame rate and bandwidth
Constant and variable bit rate (M-JPEG / H.264)
Rate Control
CBR (Constant Bit Rate)
VBR (Variable Bit Rate)
UI Layout
180° Single Broad View (1P)
2 PTZ Mode (2R)
180° Broad View + 2 PTZ Mode (1P2R)
Audio
Audio Streaming 2-way Audio
Audio Compression RTSP: G.711 64kbps
Microphone Built-in Microphone
Audio Output Line Out for extra speaker
Network and Configuration
Network Standard
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
IEEE 802.11b/g/n
Network Protocol
IPv4, TCP/IP, UDP, HTTP, HTTPS, SMTP, FTP, NTP, DNS, DDNS,
DHCP, ARP, Bonjour, UPnP, RTSP, RTP, RTCP, IGMP, PPPoE,
3GPP, ICMP, Samba
Antenna connector 1 x 3dBi (max)
Frequency 2.4GHz
RF Transmission Power
OFDM: 13dBm
CCK: 17dBm
Output Power
802.11n: 13dBm(default) +/- 1dBm
802.11g: 13dBm(default) +/- 1dBm
