PRIME / ProArt / TUF GAMING Intel 700 Series BIOS Manual 45
Offset Voltage
Allows you to configure the CPU core voltage offset value. Use the <+> or <-> to adjust the
value. The values range from 0.001V to 0.999V with an interval of 0.001V.
Configuration options: [Auto] [0.00100] - [0.99900]
You need to save the changes and reset the system for the changes to take effect.
Cache SVID Voltage
Allows you to configure the Cache Voltage requested by the Ring Domain. Result may be
influenced by Actual VRM Core Voltage.
Configuration options: [Auto] [Manual Mode] [Adaptive Mode]
The following item appears only when Cache SVID Voltage is set to [Manual Mode] .
CPU Core Voltage Override
Allows you to configure the voltage for the Cache. Use the <+> and <-> keys to adjust the
value. The values range from 0.600V to 1.700V with an interval of 0.001V.
Configuration options: [Auto] [0.60000] - [1.70000]
The following items appear only when Cache SVID Voltage is set to [Adaptive Mode] .
Offset Mode Sign
[+] To offset the Cache voltage by a positive value.
[–] To offset the Cache core voltage by a negative value.
Additional Turbo Mode Cache Voltage
Allows you to configure the amount of voltage fed to the CPU cores when running in Turbo
mode. Increase the voltage when configuring a high CPU core frequency. This voltage will
be affected by the offset value. Use the <+> or <-> to adjust the value. The values range
from 0.250V to 1.920V with an interval of 0.001V.
Configuration options: [Auto] [0.25000] - [1.92000]
Offset Voltage
Allows you to configure the Cache voltage offset value. Use the <+> or <-> to adjust the
value. The values range from 0.001V to 0.999V with an interval of 0.001V.
Configuration options: [Auto] [0.00100] - [0.99900]
You need to save the changes and reset the system for the changes to take effect.
CPU Graphics Voltage
Allows you to configure the mode of voltage fed to the CPU Graphics. Manual mode allows
user-defined values. Offset mode modified values by SVID.
Configuration options: [Auto] [Manual Mode] [Offset Mode]
