78 PRIME / ProArt / TUF GAMING Intel 700 Series BIOS Manual
The following items appear only when AIO Pump Profile is set to [Manual].
AIO Pump Point4 Temperature
When the temperature source is lower than the temperature of P4, the duty cycle
will be determined according to the P3-P4 and the temperature source. When the
temperature source is higher than the temperature of P4, the fan will operate at the
duty cycle of P4. Use the <+> or <-> keys to adjust the temperature.
AIO Pump Point4 Duty Cycle (%)
When the temperature source is lower than the temperature of P4, the duty cycle
will be determined according to the P3-P4 and the temperature source. When the
temperature source is higher than the temperature of P4, the fan will operate at the
duty cycle of P4. Use the <+> or <-> keys to adjust the fan/pump duty cycle.
AIO Pump Point3 Temperature
When the temperature source is lower than the temperature of P3, the duty cycle
will be determined according to the P2-P3 and the temperature source. When the
temperature source is higher than the temperature of P3, the fan will operate at the
duty cycle of P3-P4. Use the <+> or <-> keys to adjust the temperature.
AIO Pump Point3 Duty Cycle (%)
When the temperature source is lower than the temperature of P3, the duty cycle
will be determined according to the P2-P3 and the temperature source. When the
temperature source is higher than the temperature of P3, the fan will operate at the
duty cycle of P3-P4. Use the <+> or <-> keys to adjust the fan/pump duty cycle.
AIO Pump Point2 Temperature
When the temperature source is lower than the temperature of P2, the duty cycle
will be determined according to the P1-P2 and the temperature source. When the
temperature source is higher than the temperature of P2, the fan will operate at the
duty cycle of P2-P3. Use the <+> or <-> keys to adjust the temperature.
AIO Pump Point2 Duty Cycle (%)
When the temperature source is lower than the temperature of P2, the duty cycle
will be determined according to the P1-P2 and the temperature source. When the
temperature source is higher than the temperature of P2, the fan will operate at the
duty cycle of P2-P3. Use the <+> or <-> keys to adjust the fan/pump duty cycle.
AIO Pump Point1 Temperature
When the temperature source is lower than the temperature of P1, the fan will operate
at the duty cycle of P1. When the temperature source is higher than the temperature
of P1, the duty cycle will be determined according to P1-P2 and the temperature
source. Use the <+> or <-> keys to adjust the temperature.
AIO Pump Point1 Duty Cycle (%)
When the temperature source is lower than the temperature of P1, the fan will operate
at the duty cycle of P1. When the temperature source is higher than the temperature
of P1, the duty cycle will be determined according to P1-P2 and the temperature
source. Use the <+> or <-> keys to adjust the fan/pump duty cycle.
