PRIME / ProArt / TUF GAMING Intel 700 Series BIOS Manual
59
Map SATA Controller under VMD
Allows you to map or unmap this Root Port to VMD.
Configuration options: [Disabled] [Enabled]
Ensure to set
Map PCIE Storage under VMD
to
[Disabled]
if you set
Map SATA
Controller under VMD
to
[Enabled]
.
PCI Express Configuration
The items in this submenu allow you to configure the PCIe Speeds for the different onboard
slots.
The items in this submenu may vary according to your motherboard. Please refer to the
BIOS of your motherboard for the actual settings and options.
6.4
PCH Configuration
The items in this menu allow you to change the PCIe configurations for slots supported by
the PCH.
PCI Express Configuration
The items in this submenu allow you to configure the PCIe Speeds for the different onboard
slots supported by the PCH.
The items in this submenu may vary according to your motherboard. Please refer to the
BIOS of your motherboard for the actual settings and options.
