74 PRIME / ProArt / TUF GAMING Intel 700 Series BIOS Manual
CPU Fan Speed Low Limit
Allows you to set the lower speed limit for assigned fan/pump. A warning message will
appear when the limit is reached; the warning message will not appear if [Ignore] is
selected.
Configuration options: [Ignore] [200 RPM] [300 RPM] [400 RPM] [500 RPM] [600
RPM]
The following items appear only when CPU Fan Profile is set to [Manual].
CPU Fan Point4 Temperature
When the temperature source is lower than the temperature of P4, the duty cycle
will be determined according to the P3-P4 and the temperature source. When the
temperature source is higher than the temperature of P4, the fan will operate at the
duty cycle of P4. Use the <+> or <-> keys to adjust the temperature.
CPU Fan Point4 Duty Cycle (%)
When the temperature source is lower than the temperature of P4, the duty cycle
will be determined according to the P3-P4 and the temperature source. When the
temperature source is higher than the temperature of P4, the fan will operate at the
duty cycle of P4. Use the <+> or <-> keys to adjust the fan/pump duty cycle.
CPU Fan Point3 Temperature
When the temperature source is lower than the temperature of P3, the duty cycle
will be determined according to the P2-P3 and the temperature source. When the
temperature source is higher than the temperature of P3, the fan will operate at the
duty cycle of P3-P4. Use the <+> or <-> keys to adjust the temperature.
CPU Fan Point3 Duty Cycle (%)
When the temperature source is lower than the temperature of P3, the duty cycle
will be determined according to the P2-P3 and the temperature source. When the
temperature source is higher than the temperature of P3, the fan will operate at the
duty cycle of P3-P4. Use the <+> or <-> keys to adjust the fan/pump duty cycle.
CPU Fan Point2 Temperature
When the temperature source is lower than the temperature of P2, the duty cycle
will be determined according to the P1-P2 and the temperature source. When the
temperature source is higher than the temperature of P2, the fan will operate at the
duty cycle of P2-P3. Use the <+> or <-> keys to adjust the temperature.
CPU Fan Point2 Duty Cycle (%)
When the temperature source is lower than the temperature of P2, the duty cycle
will be determined according to the P1-P2 and the temperature source. When the
temperature source is higher than the temperature of P2, the fan will operate at the
duty cycle of P2-P3. Use the <+> or <-> keys to adjust the fan/pump duty cycle.
CPU Fan Point1 Temperature
When the temperature source is lower than the temperature of P1, the fan will operate
at the duty cycle of P1. When the temperature source is higher than the temperature
of P1, the duty cycle will be determined according to P1-P2 and the temperature
source. Use the <+> or <-> keys to adjust the temperature.
