Tray 1 paper orientation
When using paper that requires a specific orientation, load it according to the information in the following table.
Table 2-1 Tray 1 paper orientation
Paper type Image orientation Output Paper size How to load paper
Letterhead or
Preprinted
Portrait
NOTE: In Tray 1, A5
paper can be oriented
for both Landscape
and Portrait printing.
1-sided printing Letter, Legal, Executive,
Oficio (8.5 x 13), A4, A5, A6, B5 (JIS),
B5 (ISO), Postcard #10, Japanese
Postcard (Postcard (JIS)), Double
Japan Postcard Rotated (Double
Postcard (JIS))
Face-up
Top edge leading into the printer
123
Letterhead or
Preprinted
Portrait 2-sided printing Letter, Legal, Executive,
Oficio (8.5 x 13), A4, A5, A6, B5 (JIS),
B5 (ISO), Postcard #10, Japanese
Postcard (Postcard (JIS)), Double
Japan Postcard Rotated (Double
Postcard (JIS))
Face-down
Top edge leading into the printer
Prepunched Portrait
NOTE: In Tray 1, A5
paper can be oriented
for both Landscape
and Portrait printing.
1-sided printing or 2-
sided printing
Letter, Legal, Executive,
Oficio (8.5 x 13), A4, A5, A6, B5 (JIS),
B5 (ISO), Postcard #10, Japanese
Postcard (Postcard (JIS)), Double
Japan Postcard Rotated (Double
Postcard (JIS))
Face-up
Holes toward the left side of the
printer
18 Chapter 2 Paper trays ENWW
