Table 3. Model GS105PE LEDs on the front panel
Description LED
Solid green
. The switch is powered on, is operating normally, and PoE pass-through
is enabled.
Blinking green . PoE pass-through is disabled.
Off . Power is not supplied to the switch.
Power LED
Solid green
. A valid 1 Gbps port link is established.
Blinking green
. The port is transmitting or receiving packets at 1 Gbps.
Solid yellow
. A valid 10 Mbps or 100 Mbps port link is established.
Blinking yellow
. The port is transmitting or receiving packets at 10 Mbps or
100 Mbps.
Off . No port link is established.
Left LEDs (link, speed, and
activity) for all ports
Off
. The port is not delivering PoE power.
Solid green
. The port is delivering PoE power.
Blinking green
. A PoE fault occurred.
Right LEDs for PoE PSD ports
1 and 2
Off . The port is not receiving PoE power.
Solid green . The port is receiving PoE+ (802.3at) power from a PSE.
Solid yellow . The port is receiving PoE (802.3af) power from a PSE.
Right LED for PoE PD port 5
Models GS108PEv3 LEDs
This section describes the LED designations of model GS108PEv3.
Ports 1 through 4 are PoE ports. Ports 5 through 8 are regular Ethernet ports.
Table 4. Model GS108PEv3 LEDs on the front panel
Description LED
Solid green . The switch is powered on and operating normally.
Off . Power is not supplied to the switch.
Power LED
Off
. Sufficient (more than 7W of) PoE power is available.
Solid yellow
. Less than 7W of PoE power is available.
Blinking yellow
. At least once during the previous two minutes, less than 7W of PoE
power was available.
PoE Max LED
User Manual 10 Hardware
Gigabit Ethernet Smart Managed Plus Switches
