NETGEAR GS308E 8-Port Gigabit Managed Switch User Manual
Page 29
The default password is
password
. The password is case-sensitive.
The Switch Information page displays.
5. Select
VLAN
.
The Basic Port-based VLAN Status page displays.
6. If this is the first time that you are accessing this page or if you are changing the
VLAN assignment method, select the
Enable
radio button and continue with Step
A pop-up window opens, informing you that the current VLAN settings will be lost.
7. Click the
OK
button.
The pop-up window closes.
8. Click the
Apply
button.
Your settings are saved.
The Basic Port-based VLAN Group table displays.
The previous figure is an example. Your switch might provide more or fewer ports.
9. Under each port to be added to a VLAN, enter the ID of the VLAN.
You can enter a VLAN ID from 1 to the maximum number of ports that your switch
supports. If all the VLANs share an uplink to the Internet or servers, enter
all
in the
VLAN ID
field for the port that you want to use for the uplink.
Note:
If ports are members of the same LAG, you must assign them to the same
VLAN.
10. Click the
Apply
button.
Your settings are saved.
User Manual
29
Use VLANS for Traffic
Segmentation
Gigabit Ethernet Smart Managed Plus Switches
