Transducer Block Parameters
Description
Subparameter
MANUAL_OPERATIONS
Total number of times unit has been manually operated.
Subparameter CLOSE_
CONTACTOR_OPERATIONS
Total number of close contactor operations.
Subparameter OPEN_
CONTACTOR_OPERATIONS
Total number of open contactor operations.
Subparameter CLOSE_CYCLES
Total number of close cycles count.
Subparameter OPEN_CYCLES
Total number of open cycles count.
Subparameter
DRIVE_SLEEVE_TURNS
Total number of drive sleeve revolutions.
Subparameter STROKE_TIME
Length of time of last actuator operation.
DEVIATION
Float value to display the deviation between setpoint and
present value. Range: 0 to 100%.
POWER_SUPPLY
Record provides support for monitoring the supply voltage and
frequency.
Subparameter VOLTAGE
Supply voltage.
Subparameter FREQUENCY
Supply frequency.
COMPARTMENT_TEMPERATURE
Record provides support for monitoring the device compart-
ment temperature.
Subparameter VALUE
Device compartment temperature value, unit as specified by the
UNIT subparameter.
Subparameter UNIT
Unit for the device compartment temperature value,
1=Centigrade, 2=Fahrenheit and 4=Kelvin.
MOTOR_TEMPERATURE
Record provides support for monitoring the motor temperature.
Subparameter VALUE
Motor temperature value, unit as specified by the UNIT
subparameter.
Subparameter UNIT
Unit for the motor temperature value, 1=Centigrade,
2=Fahrenheit and 4=Kelvin.
