GF-100 User’s Guide
20
Menu
TOP → SOURCE STATE → Table 6.1 below
The summary information of the source signals is shown on the SUMMARY page.
Very detailed information is shown on pages other than the SUMMARY page.
<Reference>
HDMI1.4: High-Definition Multimedia Interface Specification Version 1.4
CEA-861: CEA Standard A DTV Profile for Uncompressed High Speed Digital Interfaces
Note: The GF-100 is a simplified analyzer for field supports of AV systems. Please note that it does not
provide calibrations.
[Fig. 6.3] Source status menu
Menu page
Displaying information
SUMMARY
(Source signals)
Resolution, frame rate, aspect ratio, HDMI/DVI, color space, color depth, DDC
voltage, audio format, presence or absence of HDCP, and VIC (Video
Information Code)
VIDEO TIMING
(Video signals timing)
Total number of dots/lines, active area, back porch, front porch, synchronous
signals polarity, scanning method
VIDEO FREQ.
(Video frequency)
Frame rate, horizontal synchronous signals, dot clock
AUDIO STATE 1
(Audio signals)
Sampling frequency information, audio format, and other information
AUDIO STATE 2
(Audio signals)
Other additional information
AVI INFO
(AVI InfoFrame)
Color space, color range, aspect ratio, and other information
SPD INFO
(SPD InfoFrame)
Manufacturer information
AUDIO INFO 1
(AUDIO InfoFrame)
Speaker configuration
AUDIO INFO 2
(AUDIO InfoFrame)
Audio format, the number of channels, and other information
WEB page
http://The GF-100’s IP address/source_state.html
“The GF-100’s IP address” refers to the assigned IP address given to the GF-100. The default IP address
is 192.168.001.199, and it can be changed using the settings in section “10.4.1 IP address”.
