GF-100 User’s Guide
61
12 Product specification
Source test and cable/transmission path test
Item Description
Video HDMI/DVI HDMI Deep Color (*)/DVI 1.0
TMDS single link, HDCP, TMDS clock: 25 MHz to 225 MHz
EDID emulation
Audio Digital audio Multi-channel linear PCM up to 8 channel
Sampling frequency: 32 kHz to 192 kHz, the number of quantized bits:16 bit to 24 bit
Standard level: -20 dBFS, maximum input level: 0 dBFS
Connector HDMI Type A (19 pin)・female
Function ・Displaying video status
Resolution, frame rate, aspect ratio, HDMI/DVI, presence or absence of HDCP, color space, color depth, DDC
voltage, video timing, dot clock frequency, frame information
・Displaying audio status
Audio format, the number of channels, sampling frequency, the number of quantized bits, speaker position,
InfoFrame information
・EDID emulation (with copy function)
・Comparing sent/received signals using test signals
・Outputting source status to terminal software
・Displaying each status/source status using a WEB browser
Sink test and cable/transmission path test
Item Description
Video HDMI/DVI HDMI Deep Color (*)/DVI 1.0
TMDS single link, HDCP, TMDS clock: 25 MHz to 225 MHz
Test pattern
output format
Color space: RGB/YCbCr 4:2:2/YCbCr 4:4:4
Color depth: 24 bit, 30 bit, 36 bit Deep Color
VESA: VGA/SVGA/XGA/WXGA (1280x768)/WXGA (1280x800)/Quad-VGA/SXGA/
WXGA(1360x768)/WXGA(1366x768)/SXGA+/WXGA+/WXGA++/UXGA/WSXGA+/WUXGA/QWXGA
WUXGA/QWXGA: Reduced Blanking
SDTV/HDTV: 480i/480p/576i/576p/720p/1080i/1080p
Audio Digital audio Multi-channel linear PCM up to 8 channel
Sampling frequency: 32 kHz to 192 kHz, the number of quantized bits:16 bit to 24 bit
Standard level: -20 dBFS, Output level: up to: 0 dBFS
Test tone output
format
Multi-channel linear PCM up to 8 channels
Sampling frequency: 48 kHz, the number of quantized bits:24 bit
Standard level: -20 dBFS, Output level: up to 0 dBFS
Connector HDMI Type A (19 pin)・female
Function ・Displaying sink device specification
Supported resolution, HDMI supported/not supported, HDCP compliant/not compliant, supported color space,
supported color depth, speaker position, EDID information and other information
・Test pattern output
Color bar, gray scale, cross hatch, stripe, raster, and more
・Outputting test tone
Test audio, speaker test for each audio channel (1000 Hz,400 Hz,80 Hz,40 Hz)
・Comparing sent/received signals using test signals
・Displaying each status and downloading EDID information using a WEB browser
