IDK GF-100 User Manual
Page 51
GF-100 User’s Guide
51
T O P > C A B L E T E S T [ 3 / 3 ] S T A R T : " E S C " K E Y
C O M P A R E I N G . . . _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
D D C P W : O K H P : O K S C L / S D A : O K G N D : O K
E R R D 0 : 0 D 1 : 0 D 2 : 0
Received window
Sent window
Compare
④
[Fig. 9.7] Signals comparison
The GF-100 displays “COMPAREING...” and measures the bit error by comparing the test signals and
received signals.
You can set the amount of those signals for the comparison in “9.4 The amount of test data (P53)”.
T O P > C A B L E T E S T [ 3 / 3 ] S T A R T : " S E T " K E Y
B E R = 0 % 0 / 2 4 8 8 3 2 0 b i t
D D C P W : O K H P : O K S C L / S D A : O K G N D : O K
E R R D 0 : 0 D 1 : 0 D 2 : 0
⑤
Total bit error rate
Total number of bit errors/The number of test bits
The number of bit errors in TMDS Data 2
The number of bit errors in TMDS Data 1
The number of bit errors in TMDS Data 0
T O P > C A B L E T E S T [ 3 / 3 ] S T A R T : " S E T " K E Y
B E R = 0 % 0 / 2 4 8 8 3 2 0 b i t
D D C P W : O K H P : O K S C L / S D A : O K G N D : O K
E R R D 0 : 0 D 1 : 0 D 2 : 0
11
13
15
17
19
1
3
5
7
9
12
14
16
18
2
4
6
8
10
11
13
15
17
1
3
5
7
9
12
14
2
4
6
8
10
TMDS Data 2
TMDS Data 1
TMDS Data 0
1816
19
SDA
DDC PW (+5V Power)
HP (Hot Plug Detect)
SCL
Socket side
Result of signal conduction
CEC and Utility pins are not supported.
[Fig. 9.8] Result
When the measurement of the bit error is completed, the result is displayed.
If the total number of bit errors is “0” and all signal conductions are “OK”, the cable is normal.
Even if the bit error is not “0”, video may be displayed correctly, depending on the equalizer performance of
the sink device and the output signal quality of the source device.
Table 9.2 on the next page shows the measurement results of IDK’s cables as examples.
For IDK’s 20 m/65.62 ft. or shorter cables, the acceptance criteria is fixed at “0”. For long cables, the criteria
vary depending on the usage environment.
Note: Please do not apply an extra force to the connector at the time of connection; otherwise, the
measurement may not be performed correctly.
