GF-100 User’s Guide
62
DDC monitor
Item Description
Operation Pass through
Connector HDMI Type A (19 pin)・female
Function ・Displaying DDC communication contents between the source device and sink device
(Hot plug voltage, DDC voltage, EDID and HDCP)
・Outputting communication contents to terminal software
・Displaying communication histories using WEB browser
LAN
Item Description
LAN 1 port/RJ-45 10Base-T/100Base-TX (Auto Negotiation), Auto MDI/MDI-X
Others
Item Description
AC adapter Input: AC～100 V - 240 V ± 10 %,50 Hz/60 Hz ± 3 Hz
Output: DC 12 V 3 A (the AC adapter is supplied)
Power consumption About 11 W
Dimensions 260 (W)×53.5 (H)×133 (D) mm
Weight 0.9 kg/1.98 lbs.
Temperature Operating temperature: 32°F to 104°F/0°C to +40°C
Storage temperature: -4°F to +176°F/-20°C to +80°C
Humidity Operating/Storage humidity: 20% to 90% (Non condensing)
Included items AC adapter (5.9 ft./1.8 m), 2P-3P conversion plug
* Deep color of 36 bit/pixel (12 bit/component) is supported while xvYCC, Lip Sync, 3D, ARC, HEC and CEC are not supported.
Notes:
● Specifications are subject to change without notice.
● All nominal levels are at ±5%.
