Page 46
46
(11) Troubleshooting and Cleaning
CUTION: Make sure to disconnect power cable before starting the troubleshooting.
(A) Troubleshooting of Paper jam
Remove the Table-1 and remove the paper or pieces of paper.
Open the table-2 door, remove the Table-2 and remove the paper or torn pieces of paper.
When paper jammed using less than 27.9 lbs Bond paper, eject jammed paper by force as follows:
(In case paper cannot be ejected by this method, remove jammed paper manually per the above steps.)
(1) By pressing the Plus Key for a while, the motor stats to rotate
and paper in the folding rollers is ejected.
(2) By pressing the Plus Key further, the fold stopper moves
towards the closest position of folding rollers and jammed paper
in the fold table is ejected.
Paper Jam
Plus key
