48
(C) Cleaning of Fold Roller and Paper Feed Belt
When paper feed slips, folding line does not match as desired, wrinkled paper or inner paper jam occur
frequently, it may be caused from paper dust or ink accumulation.
Clean the fold roller as shown in the below figures.
Open the top cover, remove the Table 1 and clean each Folding Roller and Paper Feed Belt.
To clean Rollers located inside machine, remove paper stack on the Paper Feed Table and move the Paper Feed
Table to the highest position.
Open Table-2 cover and remove the Table 2. Clean the folding roller installed in the depth of machine body.
Open the top cover and clean the paper feed belt.
Fold Roller
