Canon FAX-L800 User’s Guide ENGLISH
4-2 Chapter 4 Setting Up and Using Speed Dialling
Read This before Entering Telephone
Numbers
Read this section before you register numbers for speed dialling, especially if
your site has special dialling requirements like dialling through a PBX.
When you have to make calls to an outside line or an extension, you may have to
press R before you dial the outside line number or the extension number. Before
you can use the R button, you have to register it. (
Q16-6)
Entering Pauses for Dialling
If your fax is connected to a switchboard or PBX (private branch exchange), you
may have to dial a number to connect to an outside line. The outside number
must also be registered with the fax number. The switching system may also
require that you insert a pause after the outside number. For further assistance,
contact your local authorized Canon dealer sales or service representative or
your local telephone company.
Follow this procedure to enter a pause during regular dialling or when registering
a number for a speed dialling button.
1
4
7
2
5
8
0
3
6
9
ABC
GHI
PQRS
JKL
TUV
M NO
WXYZ
DEF
1. When you come to a step that asks you to enter a number for dialling, use the
buttons on the numeric keypad to enter the number.
TELEPHONE NUMBER
TEL=03
PAUSE
2. To enter a pause between two numbers, open both One-touch Speed Dialling
panels and press PAUSE. After you enter the next number, the “P” changes
to a small “p”.
TELEPHONE NUMBER
TEL=03P
PAUSE SET 3. To enter a pause at the end of a number, press PAUSE then press SET. The
pause at the end of a number appears as an upper case “P”.
TELEPHONE NUMBER
TEL=03p123 4567P
