Ivie IE-45 Manual RTA: Average Mode
Average Mode
The IE-45 Average Mode offers very powerful features that allow you to create continuous or triggered
averages of various types, as well as select the type of average that best suits your measurement.
Continuous Average Mode
In the RTA mode, tap on the “Average-A” stylus button. The default condition for the stylus button below the
Average button is “Cont.”, which indicates that you will be starting with a continuous average. When you tap the
Average-A button, the button text changes to “Count = X," where "X" is the number of samples so far collected.
You will see the sample number increment as the number of automatically collected data samples increases.
A blue line will immediately form on the RTA screen, which is the graphic representation of the average that is
being collected. The more samples collected, the slower this average display will change as short duration
acoustic events are encountered.
In Continuous Mode, the data sample collection can be paused by tapping Pause/Resume stylus button.
Tapping the stylus button again continues the sample taking process.
You may switch the screen presentation between 1/1 octave, 1/3 octave, 1/6 octave and 1/12 octave at any time
during an Average measurement. However, doing so will reset the data sample counter to zero and start the
averaging process over again.
Triggered Average Mode
Tapping the “Cont.” stylus button will switch it to “Trigger.” In this mode, data samples for averaging are taken
only when the user manually triggers a sample. Triggering a sample can be done by tapping the “Add” stylus
button. Each time a data sample is added by triggering a sample, the sample count on the Average button will
increment by one.
You can manually clear an Average Curve and reset the data sample counter to zero at any time by tapping the
“Clear” button. To exit the Average mode tap the “Count-X” stylus button.
Average Type Selection: The IE-45 Average Mode offers the power of two types of averaging. The Arithmetic
Average (Average-A) does straight arithmetic averaging. This type of average is probably best when you are
viewing the RTA screen while doing active equalization, or other dynamic, spectral adjustments. You may switch
the averaging mode to “Power Average (Average-P), which is probably more useful in measurements where the
total sound power is of prime importance - measurements such as transmission loss, or noise isolation.
Switching from Average-A to Average-P is done by tapping the "File" pull-down menu. Select "Preferences"
next, and from that menu, select either Power Average or Arithmetic Average.
Viewing an Average Curve: While the average is being taken, the blue average line is seen in the RTA screen.
To see this line more clearly, you can temporarily remove the real-time data from the display. This is done by
tapping the green “R” button immediately below the RTA display (see figure on the opposite page).
Don’t forget
to turn the real-time display back on when you’re done . . . It’ll save you a call to Ivie Tech Support!
Storing and Loading an Average Curve: When an Average Curve is displayed on the RTA screen, it is what
will be stored when you choose to store a curve. With this in mind, an Average Curve is stored in the same way
any other spectrum is stored. Simply select an empty scratch memory location (red stylus buttons indicate
empty memory locations) and tap it. The Memory Manager ("Memory" stylus button) allows the storing of any
scratch memory as a file. Similarly, stored curves can be loaded into any standard scratch memory location by
opening the Memory Manager and selecting “Load” for any of the scratch memory locations.
