FPGA Registers
iVPX7225 Installation and Use (6806800S11C)
105
7.1.9
Watchdog Re-trigger Register - 0x0A
7.1.10 Memory Write Protect Register - 0x0B
5
Watchdog Load Timer
0
WO
-
0: Don't load watchdog timer.
1: Load watchdog timer.
6
Watchdog NMI Status
0
R/W1TC
-
0: NMI not asserted.
1: NMI asserted.
7
Reserved
0
RO
-
Table 7-8 Watchdog Control Register - 0x09 (continued)
Bit #
Description
Default
LPC Access
I2C Access
Table 7-9 Watchdog Re-trigger Register - 0x0A
Bit #
Description
Default
LPC Access
I2C Access
7:0
Watchdog Re-trigger
0x00
WO
-
Writing data 0xAD re-triggers watchdog
Table 7-10 Memory Write Protect Register - 0x0B
Bit #
Description
Default
LPC Access
I2C Access
0
Ethernet Controller SPI ROM
0
R/W
RO
0: Device write is allowed unless protected by
NVMRO.
1: Device is write protected unless protection
is overridden by RTM switch.
