U N I V E R S A L M E D I A T I O N I N T E R F A C E ( U M I ) U S E R M A N U A L
04/30/09 24
TYPE [numeric, mnemonic, both: +(mnemonic)]:
↵
MNEMONIC ADDRESS [up to 8 chars]: call-ip
↵
PAD SUPPORT [yes, no: +(no)]:
↵
DIRECTORY ENTRY [up to 30 chars double quoted, none: +(none)]:
“BNS->IP call address”
↵
GROUP(S) [up to 4 groups separated by commas, none: +(none)]:
umi-rcv
↵
ORIGINATING GROUP NAME SECURITY PATTERN(S)
[comma-separated pattern list, same_as, none: +(none)]:
↵
INITIAL SERVICE STATE [in, out: +(out)]: in
↵
Next, enter sam is used to establish a SAM504 at a module address actually occupied by the
UMI. All 16 boards should be entered if the maximum number of UMI virtual ports (504) is
desired. The following table shows the recommended entries for
enter sam (port component) for
SAM504 ports corresponding to UMI originating virtual ports:
Field Value
Protocol Async
Service Type
Host
Group <Administered Receive Group>
Cable Type DCE
Baud Rate 19,200
Parity Off
Flow Control of SAM by Device
None
Flow Control of Device by SAM None
AT&T VDM on this Port No
Permanently Activated Port No
DCD/DTR leads always high No
Bits Per Character 8
Number of Stop Bits 1
Endpoint Number or Range ++
CC0> enter sam
↵
COMPONENT [module, board, port, ipgate]: mod
↵
MODULE ADDRESS: 2
↵
COMMENT [up to 60 chars double quoted]:
“Umi”
↵
TYPE [sam8, sam16, sam64, sam504, dt4000]: sam504
↵
DOWNLOAD SERVER [+(controller)]:
↵
SOFTWARE VERSION [+(standard)]:
↵
TOTAL NUMBER OF BOARDS [1-16]: 16
↵
TRUNK TYPE [hs, samsl, t1]: t1
↵
TRUNK SPEED [56k, 64k, 128k, 192k, 256k, 320k, 384k, 448k, 512k, 576k,
640k, 704k, 768k, 832k, 896k, 960k, 1.024M, 1.088M, 1.152M, 1.216M,
1.280M, 1.344M, 1.408M, 1.472M, 1.536M, 1.544M, 2.048M: +(1.544M)]:
↵
SECONDS BEFORE CALL DISCONNECT DUE TO TRUNK FAILURE
[10 second intervals, 20-420: +(50)]:
↵
