U N I V E R S A L M E D I A T I O N I N T E R F A C E ( U M I ) U S E R M A N U A L
04/30/09 52
8 A P P E N D I X A : U M I M O D U L E
M E A S U R E M E N T S
This appendix itemizes the measurements available using the display measurements ( dm )
command with the mod option. These are module-based measurements. The base
measurements are always displayed, while the error and exception counters are only displayed if
nonzero.
Interface
Type Protocol Description
10BaseT Base All Number of 10BaseT Packets Received
10BaseT Base All Number of 10BaseT Packets Transmitted.
10BaseT Except All Number of ICMP Echo Requests Received.
V.35, DSU,
RS-232 Except HDLC, FR Number of Serial Trunk Frames Received.
V.35, DSU,
RS-232 Except HDLC, FR Number of Serial Trunk Frames Transmitted.
DSU Except ATM Number of ATM AAL5 Trunk Frames Received.
DSU Except ATM Number of ATM AAL5 Trunk Frames Transmitted.
10BaseT Error All Number of Ethernet Discards (Resource).
10BaseT Error All Number of Late Collisions ( TX).
10BaseT Error All Number of Under-run. ( TX).
10BaseT Error All Number of packets which exceeded the Retry Limit ( TX ).
10BaseT Error All Number of Carrier Sense Lost ( TX ).
10BaseT Error All Number of Frame Collisions (RX).
10BaseT Error All Number of Receiver Overruns (RX).
10BaseT Error All Number of Receive CRC Errors. (RX).
10BaseT Error All Number of Short Frame Errors. (RX).
10BaseT Error All Number of Non-Aligned Frame Error. (RX).
10BaseT Error All Number of Frame Length Violations. (RX).
10BaseT Error All Number of Unsupported Protocol Frames. (RX).
10BaseT Error All Number of Invalid UDP frames. (RX).
10BaseT Error All Number of Rx Frames w/IP Header Checksum Errors. (RX).
10BaseT Error All Number of Rx Frames w/ICMP Checksum Errors. (RX).
10BaseT Error All Number of ICMP Unreachable Destination Messages (RX).
10BaseT Error IP-DSU Number of Rx Frames from Non-Peer Entity.
10BaseT Error All Number of Unknown ICMP Messages. (RX).
10BaseT Error IP-DSU Number of Packets lost from TTL Network Error. (RX).
10BaseT Error All Number of Packets with wrong IP Destination Address (RX).
10BaseT Error All Number of Rx Packets with Unknown ARP Operations. (RX).
10BaseT Error All Number of Bad ARP Reply Packets Received.
10BaseT Error All Number of RFC894 Packets with an Unknown protocol type field.
(RX).
10BaseT Error All Number of 802.3 Frames with an Unknown protocol type field.
(RX).
V.35, DSU
RS-232 Error HDLC, FR Number of Frames aborted by CTS lost (TX).
V.35, DSU
RS-232 Error HDLC, FR Number of Frames Under-Run. (TX).
