U N I V E R S A L M E D I A T I O N I N T E R F A C E ( U M I ) U S E R M A N U A L
04/30/09
25
CC0>
enter sam
↵
COMPONENT [module, board, port, ipgate]:
board
↵
MODULE ADDRESS:
2
↵
BOARD ADDRESS [1-16: +(1-16)]:
1
↵
BOARD SOFTWARE VERSION [custom, standard: +(standard)]:
↵
INITIAL SERVICE STATE [in, out: +(out)]:
in
↵
CC0>
enter sam
↵
COMPONENT [module, board, port, ipgate]:
port
↵
MODULE ADDRESS:
2
↵
BOARD ADDRESS [1-16]:
1
↵
PORT NUMBER [1-32: +(1-32)]:
↵
COMMENT [up to 60 chars double quoted]:
"umi originate vports"
↵
PROTOCOL [async, bisync, ddcmp, hdlc, sdlc, uscope, alc]:
async
↵
SERVICE TYPE[console, host, modem, 2way, terminal: +(terminal)]:
host
↵
GROUP [up to 8 chars]:
umi-rcv
↵
CABLE TYPE [dce, dte: +(dce)]:
↵
BAUD RATE [75, 110, 150, 300, 1200,
2400, 4800, 9600, 14400, 19200: +(9600)]:
19200
↵
PARITY [even, odd, off: +(off)]:
↵
FLOW CONTROL OF SAM BY DEVICE [xon/xoff, eia, none: +(none)]:
↵
FLOW CONTROL OF DEVICE BY SAM [xon/xoff, eia, none: +(none)]:
↵
AT&T VDM ON THIS PORT [yes, no: +(no)]:
↵
PERMANENTLY ACTIVATED PORT [yes, no: +(no)]:
↵
DCD/DTR LEADS ALWAYS HIGH [yes, no: +(no)]:
↵
BITS PER CHARACTER [5, 6, 7, 8: +(8)]:
↵
NUMBER OF STOP BITS [1, 2: +(1)]:
↵
INITIAL SERVICE STATE [in, out: +(out)]:
in
↵
Finally, to enable calls to be set up,
restore sam
is used to put the “SAM504” into service, which
puts the UMI virtual ports into service.
CC0>
restore sam
↵
COMPONENT [module, board, port, ipgate]:
mod
↵
MODULE ADDRESS:
2
↵
Download in progress for module 2.
Download(s) in progress. <DEL> puts process in background
Download proceeding >
Download complete for module 2.
<UMI>
vfy vport all
↵
Virtual Ports 1 - 32 :
Type ==> TCP Port w/Call Origination.
Service State ==> In Service.
PDD TCP Destination ==> 135.17.59.20 Port 23
