U N I V E R S A L M E D I A T I O N I N T E R F A C E ( U M I ) U S E R M A N U A L
04/30/09 31
setting up a PDD to a specific BNS destination address for the SAM504 ports corresponding to
the virtual port hunt group (most restrictive), or by using CUG assignments in the BNS network to
control dialing access from each originating group of SAM ports. See Appendix F for an example
scenario.
4.4.2 Telnet Console
A call to the TCP port number corresponding to the telnet console (i.e. 1023) will be blocked
unless the calling IP address belongs to at least one of the CUGs associated with the telnet
console.
4.4.3 SNMP Interface
A UDP packet sent to the SNMP interface port number will be blocked unless the sender IP
address belongs to at least one of the CUGs associated with the SNMP interface.
4.5 UMI CONFIGURATOR
This tool facilitates initial UMI configuration. The configurator is a free StarKeeper
® II NMS utility
that significantly reduces the time required to configure an entire UMI, including node and
module-based configuration. UMI Configurator Installation and Usage notes can be found in
Appendix D.
