U N I V E R S A L M E D I A T I O N I N T E R F A C E ( U M I ) U S E R M A N U A L
04/30/09 49
6 U M I S N M P A G E N T
The UMI SNMP V1 agent supports a multitude of SNMP MIB variables, SNMP trap operations,
as well as set and get
operations.
One or more SNMP managers may query the SNMP agent.
6.1 SNMP Version 1 Commands
Command Operational Result
Get Requests the values of one or more Management Information Base (MIB)
variables.
GetNext Enables MIB variables to be read sequentially, one variable at a time.
Set Permits one or more MIB values to be updated.
GetResponse Used to respond to a Get, GetNext, or Set.
Trap Indicates the occurrence of a predefined condition.
6.2 UMI SNMP MIB Variable Database
RO = Read Only Variable
R/W = Read Variable / Write Variable
SIV = Storage is Volatile
MIB Variable
Number
Name MIB Console Equivalent Access Notes
1.3.6.1.2.1.1.1.0 SysDescr MIB-II Banner Message RO
1.3.6.1.2.1.1.2.0 SysObjectID MIB-II None RO
1.3.6.1.2.1.1.3.0 SysUpTime MIB-II None RO
1.3.6.1.2.1.1.4.0 SysContact MIB-II None R/W SIV
1.3.6.1.2.1.1.5.0 SysName MIB-II None R/W SIV
1.3.6.1.2.1.1.6.0 SysLocation MIB-II None R/W SIV
1.3.6.1.2.1.1.7.0 SysServices MIB-II None RO
1.3.6.1.2.1.4.1.0 IpForwarding MIB-II None RO
1.3.6.1.2.1.4.2.0 IpDefaultTTL MIB-II None RO
1.3.6.1.2.1.4.3.0 IpInReceives MIB-II Nbr of Ethernet Pkts Rcvd RO
1.3.6.1.2.1.4.4.0 IpInHdrErrors MIB-II Nbr of Packets w/Header Errs RO
1.3.6.1.2.1.4.5.0 IpInAddrErrors MIB-II Nbr Rx Packets w/Wrong Addr RO
1.3.6.1.2.1.4.6.0 IpForwDatagrams MIB-II None RO
1.3.6.1.2.1.4.7.0 IpInUnknownProtos MIB-II Nbr of Packets w/Unk Protocol RO
1.3.6.1.2.1.4.8.0 IpInDiscards MIB-II Nbr of Packets Disc due to
Resource RO
