U N I V E R S A L M E D I A T I O N I N T E R F A C E ( U M I ) U S E R M A N U A L
04/30/09
29
Flow Control of Device by SAM
None
Node Echoes User Input
Yes
Call Hold
On
AT&T VDM on this Port
No
Permanently Activated Port
No
DCD/DTR leads always high
No
Connect Time Billing
< As needed>
Attention Character
<Per desired preference>
Attention Action
Command Mode
Bits Per Character
8
Number of Stop Bits
1
Endpoint Number or Range
++
CC0>
enter sam
↵
COMPONENT [module, board, port, ipgate]:
board
↵
MODULE ADDRESS:
2
↵
BOARD ADDRESS [1-16: +(1-16)]:
2
↵
BOARD SOFTWARE VERSION [custom, standard: +(standard)]:
↵
INITIAL SERVICE STATE [in, out: +(out)]:
in
↵
CC0>
enter sam
↵
COMPONENT [module, board, port, ipgate]:
port
↵
MODULE ADDRESS:
2
↵
BOARD ADDRESS [1-16]:
2
↵
PORT NUMBER [1-32: +(1-32)]:
↵
COMMENT [up to 60 chars double quoted]:
"UMI receive virtual ports"
↵
PROTOCOL [async, bisync, ddcmp, hdlc, sdlc, uscope, alc]:
async
↵
SERVICE TYPE [console, host, modem, 2way, terminal: +(terminal)]:
↵
GROUP [up to 8 chars]:
umi-orig
↵
PREDEFINED DESTINATION [+(none)]:
↵
CABLE TYPE [dce, dte: +(dce)]:
↵
BAUD RATE [75, 110, 150, 300, 1200,
2400, 4800, 9600, 14400, 19200, auto: +(auto)]:
19200
↵
PARITY [even, odd, off: +(off)]:
↵
FLOW CONTROL OF SAM BY DEVICE [xon/xoff, eia, none: +(none)]:
↵
