U N I V E R S A L M E D I A T I O N I N T E R F A C E ( U M I ) U S E R M A N U A L
04/30/09 47
prompt label. A console label may be up to thirty one characters in length, and may contain
spaces. The console label string may not contain the colon character (:).
5.31 Administrative Password
Syntax: admpass [old=<Old Password>]
new=<New Password> confirm=<New Password>
The admpass command is used to configure or change an administrative password for the UMI
console. The administrative password is required to use the Remove, Disconnect, or Reboot
commands. The administrative password defaults to a NULL value until changed.
The [old=<Old Password>] specifies the previous administrative password for use of this
command. This option is not required on the first configuration of the administrative password.
The new=<New Password> confirm=<New Password> specifies the administrative password.
Both values are required and must match exactly.
The administrative password takes effect immediately after the successful execution of the
command.
5.32 CONSOLE Administration
Syntax: console [cug=<<+|->CUG Number>]
The console command is used to configure or change the closed user group configuration of the
telnet console to the UMI. Up to 32 CUGs may be associated with the telnet console.
5.33 HPIO Administration
Syntax: HPIO [ RESET ]
[ ENABLE < ALL | FIBER | <10/100 PHY RANGE> > ]
[ DISABLE < ALL | FIBER | <10/100 PHY RANGE> > ]
[ AUTO < ALL | <10/100 PHY RANGE> ]
[ 10HDX < ALL | <10/100 PHY RANGE> ]
[ 10FDX < ALL | <10/100 PHY RANGE> ]
[ 100HDX < ALL | <10/100 PHY RANGE> ]
[ 100FDX < ALL | <10/100 PHY RANGE> ]
The HPIO command is used to enable or disable the physical LAN connections on the DTK41
high performance I/O module. The DTK41 operates defaults to all ports being active. Therefore,
no configuration is required unless security of the unused ports becomes an issue.
