U N I V E R S A L M E D I A T I O N I N T E R F A C E ( U M I ) U S E R M A N U A L
04/30/09
40
Type ==> TCP Port w/Call Origination.
Service State ==> In Service.
PDD TCP Destination ==> 192.168.59.251
Port 20000
Protocol ==> Asynchronous.
NULL after CR Operation ==> Transparent.
LF after CR Operation ==> Transparent.
<UMI> vfy vport 2
Virtual Ports 2 - 2 :
Type ==> TCP Port w/Call Origination.
Service State ==> In Service.
PDD TCP Destination ==> 192.168.59.251
Port 20001
Protocol ==> Asynchronous.
NULL after CR Operation ==> Transparent.
LF after CR Operation ==> Transparent.
Example 2
<UMI> vport 1
cnt=3
incr=200
dest=192.168.17.7 dport=30000
<UMI> vfy vport 1
Virtual Ports 1 - 1 :
Type ==> TCP Port w/Call Origination.
Service State ==> In Service.
PDD TCP Destination ==> 192.168.17.7
Port 30000
Protocol ==> Asynchronous.
NULL after CR Operation ==> Transparent.
LF after CR Operation ==> Transparent.
<UMI> vfy vport 2
Virtual Ports 2 - 2 :
Type ==> TCP Port w/Call Origination.
Service State ==> In Service.
PDD TCP Destination ==> 192.168.17.7
Port 30200
Protocol ==> Asynchronous.
NULL after CR Operation ==> Transparent.
LF after CR Operation ==> Transparent.
<UMI> vfy vport 3
Virtual Ports 3 - 3 :
Type ==> TCP Port w/Call Origination.
Service State ==> In Service.
PDD TCP Destination ==> 192.168.17.7
Port 30400
Protocol ==> Asynchronous.
NULL after CR Operation ==> Transparent.
LF after CR Operation ==> Transparent.
A virtual port which waits for an incoming call from the IP network is designated by
type=rcv. For
a virtual port which originates calls to the IP network (
type=orig), the PDD of the call is defined
by either the
pdd=<pdd#> or by dest=<ipaddr> and dport=<tcp_port>. These destination
options are only required for PDDs. The two forms are mutually exclusive. BNS users setting up
