U N I V E R S A L M E D I A T I O N I N T E R F A C E ( U M I ) U S E R M A N U A L
04/30/09 32
5 U M I M O D U L E C O M M A N D R E F E R E N C E
These module commands are used to configure the operation of the UMI.
Not all commands are visible all the time. Should the unit be logged out, only the login command
is visible. The reboot command places the unit in the logged-out mode.
Parameters of the form name=<value> must be entered in order, and all parameters being used
must be entered on a single command line.
‰ Commands may be entered in upper or lower case.
‰ Parameters of the form name=<value> may use upper or lower case for name.
‰ Case is preserved for values.
‰ Backspace erases one character.
5.1 LOGIN
Syntax: login passwd=<password> (default password is: initial)
The login command is only visible when the unit is in the logged out (i.e. secure) mode. The unit
enters this mode whenever a logout command is issued or when a reboot occurs for any reason.
The password is
not echo-suppressed and consists of up to seven alphanumeric characters.
Special characters are not allowed.
NOTE: The "Login" command accepts an optional form. By entering the command without
arguments, a password will be prompted for. In this alternate form, the password is not
echoed. Only asterisks are echoed (i.e. login <enter>).
5.2 LOGOUT
Syntax: logout
The logout command is only visible when the unit is logged in. The command has no arguments.
It returns the user to the logged out mode.
5.3 CHGPASS
Syntax: chgpass old=<password> new=<password> confirm=<password>
The chgpass command is only visible when the unit is logged in. The command allows the user
to change the password configured for the unit. All arguments are required for the command to
complete. The old password is the one currently in effect. The new and confirm passwords must
be identical. Passwords are up to seven characters in length. The characters are alphanumeric
and special characters are not allowed.
5.4 LOCAL
Syntax: local [ipaddr=<IP address>]
[submask=<submask>]
[tcpunreach=< ICMP | RESET >]
The local command is only visible when the unit is logged in.
The ipaddr field is the IP address of this unit.
The submask field is the subnet mask for the LAN segment on which the unit is located. It
defaults to 255.255.255.0.
