APKD DOUBLE-CASE, DOUBLE-SUCTION USER INSTRUCTIONS 26999903 07-13
Page 14 of 55 flowserve.com
3.2.1.1 Types of discharge heads
Typical discharge head types. Details (a) thru (e).
a) HF type fabricated discharge head
(Typically with square base plate)
Figure 3.3
b) TF type fabricated discharge head
Figure 3.4
c) LF type fabricated discharge head
(Typically with a circular base plate- ANSI type.
Also available with suction barrel mounting)
Figure 3.5
d) HFL type fabricated discharge head
Figure 3.6
e) HFH type fabricated discharge head
Figure 3.7
The discharge heads shown in section
3.2.1.1 (a) thru (e) are for illustration only. The shaft
and coupling arrangements vary. For the actual
configuration of the pump that has been purchased,
please refer to the drawings supplied with the pump
or order specific sectionals from Flowserve.
