APKD DOUBLE-CASE, DOUBLE-SUCTION USER INSTRUCTIONS 26999903 07-13
Page 38 of 55 flowserve.com
1. pump type and pump size
2. serial number of the pump
3. number of the required spare parts
4. reference number and name of the part as listed
in the part list or in the sectional drawing
The pump size and serial number are as shown on
the pump nameplate.
To ensure continued satisfactory
operation, replacement parts to the original design
specification should be obtained from Flowserve.
Any change to the original design specification
(modification or use of a non-standard part) will
invalidate the pump’s safety certification.
Please fill out a spare parts request form and send
it to the Flowserve customer service. Contact
Flowserve for a copy of the request form or
assistance to order spare parts (see back page for
contact information).
6.3.2
How to select recommended spares
Generally a list of spare parts supplied along with
the pump that shows the parts that are included in
each of the following two classes of recommended
spares. If you do not find such documentation
please contact Flowserve for the list.
6.3.2.1
Class I minimum
Suggested for Domestic Service when pump is
handling clean non-corrosive liquids and where
interruptions in service are not important.
6.3.2.2
6.2.2.2 Class II average
Suggested for Domestic Service when pump is
handling abrasive or corrosive liquids and where
some interruptions in continuity of service are not
objectionable.
Please contact Flowserve Sales Representative in
your area to review the spares best suited to meet
your requirements.
6.3.3
Storage of spare parts
Spares should be stored in a clean dry area away
from vibration. Inspection and re-treatment of
metallic surfaces (if necessary) with preservative is
recommended at 6-month intervals.
6.4 Recommended spares and
consumables
A list of spares and consumables are generally
included along with this User Instructions and other
documents that you have received along with the
pump and is made specifically to your order. In the
event that the list is not found, please contact
Flowserve with pump type and order no.
6.5 Tools required
Standard tools needed to maintain this pump
are follows.
 Open ended spanners / wrenches (standard
size range)
 Socket spanners / wrenches (standard size
range)
 Allen
keys/wrenches
 Standard range of screw drivers
 Soft
mallet
Other tools may be required depending
on the accessories/ special parts used per contract.
Flowserve in general is not obligated to ship the
tools with any pump shipped.
