Duramax Hyamp Long Handheld Torches Service Manual 808290
55
4 – Component Replacement
6. While holding the spring in place, slide the trigger and spring up and out of the handle. Set them aside.
7. Use a blade screwdriver to pry the start switch off the 2 mounting posts.
Figure 15
8. Disconnect the start switch by pushing the tab and pulling the start switch away from the connector.
Figure 16
Start switch
Tab
