NAMES AND FUNCTIONS
46
BASIC
CONNECTIONS
BASIC
OPERA
TION
ADV
ANCED
CONNECTIONS
SETUP
ADV
ANCED
OPERA
TION
TROUBLESHOOTING
OTHERS
ADV
ANCED
OPERA
TION
ENGLISH
ADVANCED OPERATION
2. P r e s s IN F O b u t t o n o n t h e r e m o t e
controller.
3. The list of preset channels will be displayed
on the screen of the TV monitor connected
to this unit.
P R E S E T L I S T
N O . 1 F M 8 7 . 1 0 M H z
N O . 2 F M 9 3 . 1 0 M H z
N O . 3 F M 9 4 . 7 0 M H z
N O . 1 0 F M 1 0 5 . 7 0 M H z
R E T U R N N E X T E X I T
4.
Up to 10 channels can be displayed at a
time. If there are more than 10 channels,
press INFO on the remote controller once
more to display the next page.
In a few moments the list display is cleared
automatically.
CLEARING STORED PRESET STATIONS
You can remove preset stations from the memory
using the following procedure.
3. 2.
2.
3.
1.
Recall the preset number to be cleared
with the method described in “Recalling” a
preset station.
2.
Press the MEMORY button on the front
panel or press the MEMO button on the
remote controller.
3.
The stored preset number blinks in the
display for 5 seconds. While blinking, press
the CLEAR button on the front panel or the
CLR button on the remote controller.
4. “xx CLEAR” appears on the display to
indicate that the specifi ed preset number
has been cleared.
Note
• To clear all stored preset stations, press and hold
the T.MODE and the ENTER buttons for two
seconds.
SORTING PRESET STATIONS
If you have stations memorized, and there is a gap
in the sequential order:
I.e. the stations are stored as follows
1)
87.1 MHz
2) 93.1 MHz
3) 94.7 MHz
10) 105.9 MHz
(notice there is no stations programmed for pre sets
for 4-9), you can have pre set 10 become pre set 4:
To sort the numbers, press and hold the MEMORY
and the
4 cursor buttons.
“PRESET SORT” will appear on the display and
sorting will be done.
NAME INPUT OF THE PRESET STATION.
This function allows the name of each preset channel
to be entered using alphanumeric characters.
Before name inputting, you need to store preset
stations with the preset memory operation.
2. 5. 6. 5. 4.
2.
5.
6.
5. 4.
1.
Recall the preset number to be inputted
name with the method described in
“Recalling” a preset station.
2.
Press the MEMORY button on the front
panel or press the MEMO button on the
remote controller for more than 3 seconds.
3.
The left most column of the station name
indicator fl ashes, indicating the character
entry ready status.
4. When you press the 3 or 4 cursor buttons
on the front panel or the remote controller,
alphabetic and numeric characters will be
displayed in the following order:
A ↔ B ↔ C ... Z ↔ 1 ↔ 2 ↔ 3 ..... 0 ↔ – ↔ +
↔ / ↔ (Blank) ↔ A
UP ↔
↔ DOWN
5. After selecting the first character to be
entered, press the MEMORY or ENTER
button, or press the MEMO button on the
remote controller.
The entry in this column is fi xed and the
next column starts to fl ash. Fill the next
column the same way.
To move back and forth between the
characters, press the 1 / 2 cursor buttons.
Note
• Unused columns should be filled by entering
blanks.
6. To save the name, press the MEMORY or
ENTER button on the front panel, or press
the MEMO button on the remote controller
for more than 2 seconds.
Instead of using the 3 and 4 cursor
buttons to select characters, characters
can be input from the numeric keys of the
remote controller. See the below table for
a correspondence between characters and
numeric keys.
Numeric
keypad
Display
1 A → B → C → 1 → A
2 D → E → F → 2 → D
3 G → H → I → 3 → G
4 J → K → L → 4 → J
5 M → N → O → 5 → M
6 P → Q → R → 6 → P
7 S → T → U → 7 → S
8 V → W → X → 8 → V
9 Y → Z → space → 9 → Y
0 – → + → / → 0 → –
