61
APPENDIX D: Multiple Controller (RS‐485) Wiring Diagram
Computer
RS485 Converter
TC-36-25 RS485 #1 TC-36-25 RS485 #3 TC-36-25 RS485 #5
TC-36-25 RS485 #6
TC-36-25 RS485 #2 TC-36-25 RS485 #4
121 Ohm
Resistor
121 Ohm
Resistor
