HEIDENHAIN TNC 128 113
3.4 W
o
rk
ing with the file manag
e
r
Displaying graphics files
To open graphics files with the extension bmp, gif, jpg or png directly
on the TNC, proceed as follows:
 Call the file manager
 Select the directory in which the graphics file is saved
 Move the highlight to the graphics file
 Press ENT: The TNC opens the graphics file in its own
application using the ristretto additional tool
With the key combination ALT+TAB you can always return to the TNC
user interface while leaving the graphics file open. Alternatively, you
can also click the corresponding symbol in the taskbar to switch back
to the TNC interface.
More information on how to use the ristretto function is provided
under Help.
To exit ristretto, proceed as follows:
 Use the mouse to select the File menu item
 Select the menu item Quit: The TNC returns to the file manager
