176 Programming: Subprograms and program section repeats
7.
6 Pr
ogr
amming examples
6 X+15 R0 FMAX M3 Move to starting point X for group 1
7 Y+10 R0 FMAX Move to starting point Y for group 1
8 CALL LBL 1 Call the subprogram for the group
9 X+45 R0 FMAX Move to starting point X for group 2
10 Y+60 R0 FMAX Move to starting point Y for group 2
11 CALL LBL 1 Call the subprogram for the group
12 X+75 R0 FMAX Move to starting point X for group 3
13 Y+10 R0 FMAX Move to starting point Y for group 3
14 CALL LBL 1 Call the subprogram for the group
15 Z+250 R0 FMAX M30 End of main program
16 LBL 1 Beginning of subprogram 1: Group of holes
17 CYCL CALL Hole 1
18 IX+20 R0 FMAX M99 Move to 2nd hole, call cycle
19 IY+20 R0 FMAX M99 Move to 3rd hole, call cycle
20 IX-20 R0 FMAX M99 Move to 4th hole, call cycle
21 LBL 0 End of subprogram 1
22 END PGM SP1 MM
