HEIDENHAIN TNC 128 205
8.8 A
d
ditional functions
3 - Spindle speed S
4 - Tool length oversize DL
5 - Tool radius oversize DR
6 - Automatic TOOL CALL
0 = Yes, 1 = No
7 - Tool radius oversize DR2
8 - Tool index
9 - Active feed rate
Values programmed immediately
after TOOL DEF, 61 1 - Tool number T
2 - Length
3 - Radius
4 - Index
5 - Tool data programmed in TOOL DEF
1 = Yes, 0 = No
Active tool compensation, 200 1 1 = Without oversize
2 = With oversize
3 = With oversize
and oversize from
TOOL CALL Active radius
2 1 = Without oversize
2 = With oversize
3 = With oversize
and oversize from
TOOL CALL Active length
3 1 = Without oversize
2 = With oversize
3 = With oversize
and oversize from
TOOL CALL Rounding radius R2
Active transformations, 210 1 - Basic rotation in MANUAL OPERATION mode
2 - Programmed rotation with Cycle 10
3 - Active mirrored axis
0: Mirroring not active
+1: X axis mirrored
+2: Y axis mirrored
+4: Z axis mirrored
Group name, ID no. Number Index Meaning
