HEIDENHAIN TNC 128
157
5.3 T
ool compensation
Entering radius compensation
Radius compensation is entered in a positioning block. Enter the
coordinates of the target point and confirm your entry with ENT
The TNC extends the traverse path of the tool by the
tool radius
The TNC shortens the traverse path of the tool by the
tool radius
Select tool movement without radius compensation
or cancel radius compensation: Press the ENT key
Terminate the block: Press the END key
TOOL RADIUS COMP: R+/R–/NO COMP?
