456 Cycles: Coordinate transformations
1
8
.8 Pr
ogr
amming examples
10 CYCL DEF 7.0 DATUM SHIFT Datum shift for group 2
11 CYCL DEF 7.1 X+75
12 CYCL DEF 7.2 Y+10
13 CALL LBL 1 Call the subprogram for the group
14 CYCL DEF 7.0 DATUM SHIFT Datum shift for group 3
15 CYCL DEF 7.1 X+45
16 CYCL DEF 7.2 Y+60
17 CALL LBL 1 Call the subprogram for the group
18 Z+250 R0 FMAX M30 End of main program
19 LBL 1 Beginning of subprogram 1: Group of holes
20 X+0 R0 FMAX Move to 1st hole
21 Y+0 R0 FMAX M99 M3 Move to 1st hole, call cycle
22 X+20 R0 FMAX M99 Move to 2nd hole, call cycle
23 Y+20 R0 FMAX M99 Move to 3rd hole, call cycle
24 X-20 R0 FMAX M99 Move to 4th hole, call cycle
25 LBL 0 End of subprogram 1
26 END PGM SP1 MM
