442 Cycles: Coordinate transformations
1
8
.1 F
undamentals
18.1 Fundamentals
Overview
Once a contour has been programmed, you can position it on the
workpiece at various locations and in different sizes through the use
of coordinate transformations. The TNC provides the following
coordinate transformation cycles:
Effect of coordinate transformations
Beginning of effect: A coordinate transformation becomes effective as
soon as it is defined—it is not called separately. It remains in effect
until it is changed or canceled.
To cancel coordinate transformations:
 Define cycles for basic behavior with a new value, such as scaling
factor 1.0
 Execute a miscellaneous function M2, M30, or an END PGM block
(depending on machine parameter clearMode).
 Select a new program
Cycle Soft key Page
7 DATUM SHIFT
For shifting contours directly within the
program or from datum tables Page 443
247 DATUM SETTING
Datum setting during program run Page 449
8 MIRROR IMAGE
Mirroring contours Page 450
11 SCALING
For increasing or reducing the size of
contours Page 452
26 AXIS-SPECIFIC SCALING FACTOR
For increasing or reducing the size of
contours with scaling factors for each
axis Page 453
