Block Move Instructions

5-11

Initiator Mode

In Target mode, the Opcode bit defines the following
operations:

These instructions perform the following steps:

1. The LSI53C825A verifies that it is connected to the

SCSI bus as an Initiator before executing this
instruction.

2. The LSI53C825A waits for an unserviced phase to

occur. An unserviced phase is any phase (with SREQ/
asserted) for which the LSI53C825A has not yet
transferred data by responding with a SACK/.

3. The LSI53C825A compares the SCSI phase bits in

the

DMA Command (DCMD)

register with the latched

SCSI phase lines stored in the

SCSI Status One

(SSTAT1)

register. These phase lines are latched

when SREQ/ is asserted.

4. If the SCSI phase bits match the value stored in the

SCSI

SCSI Status One (SSTAT1)

register, the

LSI53C825A transfers the number of bytes specified
in the

DMA Byte Counter (DBC)

register starting at

the address pointed to by the

DMA Next Address

(DNAD)

register. If the opcode bit is cleared and a

data transfer ends on an odd byte boundary, the
LSI53C825A stores the last byte in the

SCSI Wide

Residue (SWIDE)

register during a receive operation,

or in the

SCSI Output Control Latch (SOCL)

register

during a send operation. This byte is combined with
the first byte from the subsequent transfer so that a
wide transfer can complete.

OPC

Instruction Defined

0

CHMOV

1

MOVE
