RCF ZM 2124 240W 6 Zones Powered Master Unit User Manual
Page 16
16
ENGLISH
58
24 V OUT (removable connector)
24 V dc output for logic inputs (GPI) and external equipment (I max: 800 mA).
59
DRY CONTACT (removable connector)
Dry contact that will be closed in case of a fault is detected in the main unit.
60
GPO (‘Generic Purpose Outputs’, removable connector)
10 logic outputs that are activated (the 2 pins get shorted) when paging their respective
zone or due to a GPI command.
For instance, the GPO 3 is on when paging the zone 3.
61
EXT. AMP IN (ZM 2124 only, removable connector)
Input for the connection of the external amplifier 100 V output when ZM 2124 is set to
the dual amplifier mode (through the respective dip-switch
28
).
The external amplifier is used for paging only and its input needs to be linked to the ZM
2124 PRE OUT
34
.
t
he
external
amplifier
shall
have
enough
power
for
all
loudspeakers
(
suggested
: 240 w,
like
the
internal
amplifier
power
).
i
f
Zm 2124
is
set
to
the
single
amplifier
mode
,
the
external
amplifier
input
is
not
used
at
all
.
62
INT. AMP OUT (ZM 2124 only, removable connector)
Direct amplifier 100 / 70 V output to loudspeakers (not affected by zone selection).
Each loudspeaker shall have a line transformer with the input voltage equal to the line
voltage (70 / 100 V).
The loudspeaker total power (considering all the 6 zones) shall not be higher than the
amplifier maximum power (240 W).
100 V CONSTANT VOLTAGE LINE
0 70V 100V
61
34
0 dB
100 V
