20
ENGLISH
SPECIFICATIONS
ZM 2124 ZM 2100
INTERNAL AMPLIFIER TYPE Analogue (no internal amplifier)
INTERNAL AMPLIFIER MAX. OUTPUT POWER 240 W (no internal amplifier)
INTERNAL AMPLIFIER OUTPUT VOLTAGE 100 – 70 V (direct), 100 V (6 zones) (no internal amplifier)
FREQUENCY RESPONSE (+1 / –3 dB)
MIC: 60 Hz ÷ 15 kHz
AUX: 50 Hz ÷ 20 kHz
DISTORTION (at max. power) < 1% (no internal amplifier)
MIC input sensitivity 1.5 mV (– 54 dBu)
MIC input signal / noise ratio > 60 dB
MIC input impedance 600 Ω (balanced)
LINE input sensitivity 200 mV (– 12 dBu)
LINE input signal / noise ratio > 70 dB
LINE input impedance 600 Ω (balanced)
AUX input sensitivity 200 mV (– 12 dBu)
AUX input signal / noise ratio > 75 dB
AUX input impedance 10 kΩ (unbalanced)
INPUT 1÷4, AUX BASS tone control 100 Hz ± 10 dB
INPUT 1÷4, AUX TREBLE tone control 10 kHz ± 10 dB
EMERGENCY input sensitivity 100 mV (balanced audio signal), 100 V line
EMERGENCY input s/n ratio > 70 dB
EMERGENCY input impedance 600 Ω (100 mV balanced audio signal)
PAGING (RJ 45) input sensitivity 1 V (+ 2 dBu)
PRE OUT max. output level 1 V
MOH signal max. output level 1 V (+ 2 dBm @ 600 Ω, balanced)
MOH amplified output power (8 Ω) 1 W (on a 8 Ω load)
AMPLIFIER 100 V input max. power 240 W
POWER SUPPLY 115 V / 230 V ac, 24 V
MAX. POWER CONSUMPTION 720 W 100 W
OPERATING TEMPERATURE – 10 ÷ + 45 °C (+ 14 ÷ + 113 °F)
DIMENSIONS (w, h, d) 430 mm, 133 mm, 365 mm (19” rack, 3 units)
NET WEIGHT 16.1 kg 8.2 kg
