9
ENGLISH
TRIGGER STATE SETTING
It is possible to select among 3 different options:
- ZONE TRIGGER: when a logic input (GPI) is linked to 24V OUT, the output
zone (the music bus) and the logic output (GPO) having the same number
are activated.
- HIGH TRIGGER: when a logic input (GPI) is not linked to 24V OUT, the logic
output (GPO) having the same number is activated.
- LOW TRIGGER: when a logic input (GPI) is linked to 24V OUT, the logic
output (GPO) having the same number is activated.
REVISION
The current hardware (HW) and software (SW) releases are displayed.
P
keys
Press (up) or (down) to scroll a menu.
{ OK key
Press to enter a menu or select an option.
} CANCEL key
Press to return to the previous menu (one step back).
q
ESC key
Press to exit from the current menu and return to the display main page.
w MASTER VOLUME keys
Press either ‘+’ to increase the volume or ‘–’ to decrease it.
The master volume level (0 ÷ 100) is displayed on the LCD.
e POWER LED
LED lit when ZM 2124 / 2100 is operating (POWER ON).
r PRIORITY LED
LED lit when the priority function is activated.
t
OVERLOAD LED (ZM 2124 only)
LED (when lit) indicating the internal amplifier overload.
y ALL ON key with LED
Press to select all the output zones. The ‘ALL ON’ and all zone ‘ON’ LEDS will get lit.
u VU METER (LED bar, ZM 2124 only)
LED bar indicating the signal level of the mix sent to the internal amplifier.
0
d
B =
signal level that allows to get the amplifier maximum output power
.
i
Zone ON switches (A to F)
Press one or more switches to turn on / off the music bus on their respective zones.
Each LED is steady lit when its respective zone is selected (or flashing when paging).
o
Zone level controls ( A to F , ZM 2124 only)
Each control adjust the zone ‘music bus’ level from –15 dB to 0 dB (no attenuation) in
steps of 3 dB.
