Dexibell CLASSICO L3 76-Organ - Manual (Page 14)

14
Quick Guide
5
BASS
ORCHESTRA
ORGAN
PIANO HARPSICHORD
TUNING TEMPERAMENT TRANSPOSE
1.
Rotate the knob to set the input level of the signals
received via AUDIO IN sockets.
Adjust the AUDIO IN Level
By switching between sound set, you can change the overall
tonal character and feel of the entire organ. "USER 1" and
"USER 2" allow you to import sounds set downloadable from
www.dexibell.com site.
1.
Press the button repeatedly until the indicator of the desired sound set
lights.
Change the Organ Sound Set
You can adjust the reference pitch by choosing one of seven
classic fixed settings: 392Hz, 415Hz, 432Hz, 440Hz (default),
442Hz, 444Hz, 466Hz.
If you’re playing the CLASSICO L3 together with other
instruments in an ensemble, you can adjust the pitch ([FINE]
knob) to match the other instruments if necessary.
1.
Press the [PRESET] button repeatedly until the indicator of the desired
pitch lights.
2.
Rotate the [FINE] knob to adjust the tune, if necessary.
Select a Classical Tuning
The CLASSICO L3 allows you to easily change the
temperament.
1.
Press the [SCALE] button repeatedly until the indicator of the desired
temperament lights.
Select a Temperament (SCALE)
This function improves the sound of the STRING and CHOIR
family adding notes to the played chord .
1.
Select a sound of the STRING and CHOIR family.
2.
Press the [CHORD ENHANCER] to activate the function.
The [ENHANCER] button indicator lights and the Chord Enhancer function is active
3.
Play a chord on the keyboard.
The Chord Enhancer function adds notes to the chord you played .
FUNCTION/EXIT
1.
Press and hold the [FUNCTION/EXIT] to enter the function mode.
2.
Press the Tilt Tabs to enable or disable functions. See. 42.
Improve the sound (CHORD ENHANCER)
You can transpose your playing without changing the position at which you play the
keys.
1.
Use the [-] [+] buttons to adjust the transposition.
The indicator shows the transposition value.
Change the Pitch of the Keyboard (TRANSPOSE)
0 1 2
Organ Sound
Orchestral Sound Orchestral Sound
Organ Sound
Selecting a Piano Sound
MANUAL I division
These buttons allow you to select piano sounds for the
relative division. The Piano section cannot be used at
the same time as the Organ, and Orchestral.
1.
Press one of buttons of the "PIANO" section to recall a sound.
The indicator will light, and the sound will be selected.
