Dexibell CLASSICO L3 76-Organ - Manual (Page 45)

45
Keyboard Touch Response
See "Safely Remove the USB Memory" (p. 18)
Keyboard Touch Response
[ FUNCTION/EXIT ] button  40
If the keyboard response doesn't meet your taste, you can adjust it. You
can choose up to four dynamic responses. This parameter adjusts the
keyboard response for Piano and Orchestral sounds only.
Piston Setting Explanation
LIGHT PLUS
This setting produces the
lightest keyboard touch.
LIGHT
Use this setting to achieve
fortissimo playing with a less
forceful touch.
NORMAL
Medium velocity sensitivity.
The keyboard responds to
velocity changes, but the
maximum volume can be
obtained more easily than
with “HEAVY”.
HEAVY
Select this setting for
maximum expressiveness.
Even small variations of the
force with which you strike a
key produce audible changes.
The trade off is, however,
that you have to strike the
keys forcefully to reach the
maximum volume.
BLUETOOTH (make it visible)
[ FUNCTION/EXIT ] button  50
The CLASSICO L3 is equipped with Bluetooth® Audio function.
Thanks to this technology, you'll be able to stream music wirelessly from a
Bluetooth® capable smartphone, tablet or computer to the CLASSICO L3.
See "Wireless Function" (p. 40).
CRESCENDO PEDAL
[ FUNCTION/EXIT ] button  60
Piston Setting Explanation
Crescendo
Use this selection to use an
expression pedal connected
to the [CRESCENDO] socket as
crescendo [DEFAULT].
Damper
Use this selection to use an
continuous pedal connected
to the [CRESCENDO] socket
as damper pedal. It is
recommended to play piano
sounds.
CRESCENDO SETTING MODE
[ FUNCTION/EXIT ] button  70
The crescendo pedal incrementally activates a predetermined selection
of tilt tabs as it is pressed forward and removes tilt tabs as it is depressed
backward. This predetermined selection start with very quiet (pianissimo)
to very loud (TUTTI).
If you need, you can edit and choose which tilt tabs you want to activate
for each step. Refer to "Changing the Settings for Crescendo" (p. 31).
IMPORT CRESCENDO SETTING
[ FUNCTION/EXIT ] button  80
This procedure lets you import crescendo settings previously saved in the
USB Memory. This function may be useful as a backup of your work.
1.
Insert an USB Memory to save your data. See "Connecting an USB Memory
(commercially available)" (p. 18).
2.
Enter in function mode selecting the [80] tilt tab. See "General procedure"
(p. 42).
The crescendo setting is now imported in the internal memory.
NOTE
If the crescendo file is missing in the Memory USB, all tilt tabs flash to
indicate the error.
EXPORT CRESCENDO SETTING
[ FUNCTION/EXIT ] button  90
This procedure lets you export crescendo settings in the USB Memory. This
function may be useful as a backup of your work.
1.
Insert an USB Memory to save your data. See "Connecting an USB Memory
(commercially available)" (p. 18).
2.
Enter in function mode selecting the [90] tilt tab. See "General procedure"
(p. 42).
The crescendo setting is now saved in a file named " crescendo.csv " in the root
directory of the USB Memory.
NOTE
When you save a crescendo setting, it will overwrite any crescendo
setting already stored into USB memory.
