Dexibell CLASSICO L3 76-Organ - Manual (Page 35)

35
Practice with Song Player
13
The CLASSICO L3 can play back audio files in the mp3 and WAV formats
directly from a USB memory you connect to its USB MEMORY port.
You can practice playing along backing song.
The CLASSICO L3 can play back the following file types:
File Type Extension
Audio files
.mp3
.wav
.aiff or .aif
Before Playing Songs
Before being able to play back audio (mp3 or WAV) on the CLASSICO L3 ,
you must first appropriately rename them. This operation is necessary to
select a song by a numerical prefix.
In second instance, you need to copy the songs into a USB Memory.
For performing these operations you need a personal computer.
Rule Naming Audio Files
1.
Use your personal computer to rename the songs adding
a number to their name.
Here is an example: if the file is named “OliebeSeele.wav” and
another one called “GottDurchDeineGüte.mp3”, consider renaming
them as follows to
01_ OliebeSeele.wav
02_ GottDurchDeineGüte.mp3
You can use the prefixes from [01_] to [ 99_].
Copying Audio Files to an USB Memory
2.
Insert your USB Memory into the USB socket of your
computer.
3.
Create in the root directory of USB Memory the folder
"SONG".
4.
Copy all audio files previous renamed into the "SONG"
folder of the USB Memory.
SONG
MP3 WAV MP3
5.
Disconnect your USB Memory safely.
NOTE
Be aware that the CLASSICO L3 can only play back files located
in the USB memory’s "SONG" folder.
Selecting and Playing a Song
1.
Insert an USB Memory that contains songs. See
"Connecting an USB Memory (commercially available)" (p.
18) and see "Before Playing Songs" (p. 35).
Select the song
1.
Press the [SONG] button to enter in SONG mode. Its
indicator lights.
/
VALUE/REV TYPE
OBOE TRUMPET
FLUTE VIOLIN
REVERB PLAYER
All tilt tabs light off temporarily.
NOTE
The SONG mode is active momentarily. After few seconds
without pressing any tilt tab, the instrument leaves this mode. If
necessary, press again the [SONG] button (step 1).
2.
To select the song, enter a number between “1” and “99"
using the PEDAL, MANUAL I and MANUAL II tilt tabs.
PEDAL MANUAL I MANUAL II
10 20 30 40 50 60 70 80 90 1 2 3 4 5 6 7 8 9
See the numbers below the tilt tabs.
To enter “1”, just press
[VOX HUMANA 8]
(number “1”)
To enter “39”, press [POSAUNE 16] (number
“30”) followed by [TREMULANT] “9”) (in that
order).
NOTE
The song number " 99 " recall your song preciously recorded. See
"Recording Your Performance" (p. 37)
