Specifications
20
ITEMS CLASSICO L3 |
KEYBOARD TYPE • 76 Keys with dynamic
TONE GENERATOR T2L: Sampling and Modelling Technology
MODELLING Reactive to player articulation (Orchestral sounds)
SAMPLING XXL wave size, holophonic recording up to 15 seconds on lower piano notes
SOUND WAVE FORMAT 24 bit linear - 48 KHz (Internal processing and DSP at 32 bit floating)
DIGITAL ANALOG CONVERTION (DAC) 24 bit linear - 48 KHz, Dynamic Range, S/N:106dB
MAXIMUM POLYPHONY Unlimited with 320 Oscillator
ORGAN TYPES
Baroque, Romantic, Symphonic, Classic, Positive, User1*, User2*
* downloadable with file extensions .DXS
PEDAL STOP 3
MANUAL I STOP 7
MANUAL II STOP 6
ORCHESTRAL VOICES 34
MEMORY PISTONS 4 x 3 Banks under the keyboard (The data can be saved or loaded on the USB Memory)
KEYBOARD MODE 3 Parts (MANUAL I, MANUAL II, PEDAL)
TOUCH SENSITIVITY 4 Types + Fixed
REVERB 7 Types
TREMULANT 3 Types
MASTER EQUALIZER Tone control
MASTER TUNING 7 hystorical presets + fine adjustable
TRANSPOSER '+6, - 6 semitones
CHORD ENHANCER Yes
TEMPERAMENT 7 Types
PLAYER AUDIO .wav, .aiff, .mp3, in all format, frequency and bit rate
RECORDER AUDIO .wav (48 kHz, 32-bit floating) on USB Memory
MASTER TUNING YES: 415,4Hz to 466,1 Hz (adjustable increments of 0,1 Hz) + 2 Preset (440 Hz, 442 Hz)
WIRELESS CONNECTION • Bluetooth® audio streaming
RHYTHM PATTERNS X MURE APP for i-Phone and i-Pad (FREE) with multitracks audio patterns
POWER PORT to connect the USB LED lamp
CONNECTORS
DC IN socket for supplied AC adaptor
AUDIO IN jack Stereo miniature phone type
Output (L/Mono, R)
jacks
1/4-inch phone type x 2
Phones jacks
1 x Stereo miniature phone type
1 x Stereo 1/4-inch phone type
USB COMPUTER port Type B
USB MEMORY port Type A
EXPRESSION socket Assignable
DAMPER Pedal
(HOLD) socket
Assignable
CRESCENDO PEDAL Assignable
SPEAKERS 2 Full range x 8.9 cm (3,5 inches)
RATED POWER OUTPUT 35 W x 2 max @ THD+N < 0.1%
VOLUME LEVEL SPL 108.1 dB max
DSP on
AMPLIFIER
Digital Bass
Enhancer
Yes
Dynamic Eq Yes
3 Band Compressor Yes
Power Supply 24V DC 2.5A , supplied AC/DC adaptor
POWER CONSUMPTION
Stand By: < 0,2 W
Power On: 10 W
Average: 14 W
Maximum: 30 W
"ErP" LEVEL VI for Echo efficiency on stand-by consumption
