33
Working with Memory Pistons
12
The CLASSICO L3 provides Memory Pistons that allow you to store almost
all settings (or registrations) you make on the front panel. You can save
your settings in 12 memories (4 memories x 3 banks).
From factory, these twelve memories already contain useful settings, but
feel free to overwrite their contents with your own registrations.
Additional registrations can be stored or loaded directly from an external
USB Memory.
MEMO
You can recall the single registration via MIDI. See "Recalling
Memories via MIDI" (p. 38).
Saving Your Settings in a Memory
1.
Set the tilt tabs, buttons and other functions so that you
hear the combination of sounds you want to store.
2.
Press [M1, M2 or M3] piston to select the memory bank
you want to save.
PHONES AUDIO IN
The piston you selected lights.
3.
Hold down the [1,2,3,4] piston that corresponds to the
memory where you wish to save your settings.
PHONES AUDIO IN
The memory piston you selected flashes and then lights steady to
indicate that the registration was saved.
NOTE
The settings previously saved in this memory will be overwritten
by your new registration.
Recalling Your Settings
1.
If necessary, press the [M1, M2 or M3] piston to select the
bank that contains the settings you need.
2.
Press [1]~[4] piston to load the registration of the
corresponding memory.
Cancel Function
This function is useful to quickly switch off all tilt tabs and orchestral
sounds.
1.
Press the [0] piston.
PHONES AUDIO IN
All tilt tabs and orchestral button switch off.
Exporting a Registration Set to an USB
Memory
This procedure lets you export the 12 registrations in a file into USB
Memory. This function may be useful as a backup of your work.
You can save up to 12 registration set (12 files) into a USB Memory.
1.
Insert an USB Memory to save your data. See "Connecting
an USB Memory (commercially available)" (p. 18).
2.
Press and hold the [FUNCTION/EXIT] button.
PIANO HARPSICHORD
TUNING TEMPERAMENT TRANSPOSE
The [FUNCTION/EXIT] button flashes to indicate that we are in
function mode. All other indicators go dark.
3.
Press the lower part of the "2" tilt tab to select the EXPORT
MEMORY function.
Now you have to choose in which "location" (file) of the USB
memory you want save.
You can save up to 12 registration set (files) in to USB Memory. Each
location is selectable through the [M1]~[M3] and [1]~[4] memory
pistons.
For example, if you want to save the set in the location 1.1, you have
to select [M1] and [1] memory piston. If you want to save in the
location 3.2, press the [M3] and [2] memory piston. The possible 12
location are [1~3].[1~4].
NOTE
